Engineered for excellence with cutting-edge technology and precision manufacturing
Adopting a strict sealing structure and an electronic control system with a three-proof coating process, it effectively resiesses the erosion of acid, alkali, gas and liquid, ensuring that the equipment can still operate reliably in various complex industrial environments such as damp and corrosive conditions. Significantly reduce the failure rate and maintenance frequency caused by environmental factors, ensure the continuity and stability of your production process, and extend the service life of equipment.
By adopting new rectifier devices, the rectifier voltage loss is reduced to only 0.1-0.2V, significantly enhancing the overall conversion efficiency of the machine. This not only directly reduces power waste and heat dissipation burden, but also significantly saves your electricity bill, especially suitable for continuously operating electroplating production lines. While enhancing the reliability and lifespan of power supplies, it helps enterprises achieve the sustainable development goal of energy conservation and consumption reduction.
It supports multiple communication methods such as RS485/232, Modbus and remote controllers, and can be easily connected to PLCS, industrial control computers or central monitoring systems. Realize centralized control of multiple power supplies, remote parameter setting and real-time status monitoring, significantly enhancing the degree of automation and management efficiency of the production line, and providing a reliable foundation for data traceability and intelligent factory integration.
QEEHUA Power's unique cooling system significantly reduces the volume and weight of the equipment and optimizes the size of the front panel. This not only enhances space utilization, making the production line layout more compact and flexible, but also facilitates installation, maintenance and system integration. It helps you configure more equipment within a limited space and effectively reduces overall operational and space costs.
It adopts a patented dual reflux heat dissipation structure, significantly reducing the operating temperature of the machine body and key components, and minimizing heat loss. This not only directly enhances the overall rectification efficiency of the machine, but also extends the service life of the power supply, ensuring stable output under continuous high-load operation, reducing the risk of faults and maintenance costs caused by overheating, and providing a long-lasting and reliable power guarantee for your high-intensity electroplating production.
Precision-engineered parameters for optimal performance and reliability
| Parameter | Value | Unit | Note |
|---|---|---|---|
|
Input Voltage
|
3-Phase 380VAC±10% | - | - |
|
Voltage Regulation Accuracy
|
1% or Less | - | - |
|
Steady Flow Accuracy
|
1% or Less | - | - |
|
Power Factor
|
PF≥0.95 (Under Rated Working Conditions) | - | - |
|
Regulation Mode
|
RS485 Communication, Remote Controller | - | - |
|
Protection Mode
|
Over Temperature, Over Current, Lack Of Phase | - | - |
|
Conversion Efficiency
|
≥93% (Maximum Efficiency 95%) | - | - |
|
Health Status
|
Long - term Full Load Continuous Operation | - | - |
|
Place of Use
|
Indoor, No Direct Sunlight | - | - |
|
Altitude
|
Below 2500 m | - | - |
|
Output Voltage
|
0−12V/0−24V Adjustable Linear | - | - |
|
Output Current
|
0−2000A Adjustable Linear | - | - |
|
Temperature Environment
|
−20 ∘ C−45 ∘ C | - | - |
|
Current Ripple
|
1% or Less | - | - |
|
Class of Protection
|
Maximum IP54 | - | - |
|
Control Mode
|
CC & CV | - | - |
Get personalized recommendations based on your specific electroplating requirements. Our technical team will help you find the perfect solution.
Precise measurements for optimal installation planning
| Model | Width (mm) | Depth (mm) | Height (mm) | Notes |
|---|---|---|---|---|
| 0-400A/0V-12V | 234 | 330 | 203 | |
| 400-600A/0V-12V | 222.9 | 370 | 245.5 | |
| 600A-1200A/0V-12V | 263 | 426.2 | 232.3 | |
| 1500A-2000A/0V-12V | 383 | 587.7 | 202 | |
| 2500A-3000A/0V-12V | 383 | 667.7 | 202 | |
| 3000A-4000A/0V-12V | 383 | 817.7 | 202 |
QEEHUA stays at the forefront of global technological advancement, committed to providing customers with high-quality power supplies and professional integrated services.
With advanced design and extensive rectifier manufacturing experience, we deliver optimal power solutions and the most stable, efficient power supplies for our users.
Next-generation IGBT modules with advanced circuit design achieve >95% conversion efficiency and only 0.1-0.2V voltage drop
Voltage and current regulation accuracy both exceed <1%, ensuring consistent current density during electroplating
Supports RS485/232, Modbus communication interfaces for remote control and real-time monitoring
Water-cooled and air-cooled series optimized for different power requirements with compact structure and high power density
